MPM-SPLIT TECH SPECS

SPLIT MOTORISED MOVING PANEL MECHANISM

The MPM-SPLIT is a motorised moving panel mechanism, designed to split two panels horizontally, creating a pocket door / sliding partition. The MPM-SPLIT is designed to be completely concealed within the wall or ceiling to give a perfect finish with a soft open and close feature, creating a smooth and flawless motion.

With multiple control options as standard, including switch, contact closure, motion sensor and IR, the MPM-SPLIT is a fully functional mechanism created to be integrated into any residential or commercial environment. Safety features include an anti-trap system which prevents the doors from closing when an obstruction is detected.

  • Quiet Smooth Action with Variable Speed Motion
  • Easily Adjustable Switch Stops
  • Simple Mounting Detail

HAND CRAFTED IN HOUSE

-
- -
-

TECHNICAL SPECIFICATION

PRODUCT CODE MPM-SPLIT
FINISH (CUSTOM AVAILABLE) BLACK PAINT - RAL 9005
MAX WEIGHT 80KG (176LBS)
MAXIMUM TRAVEL PER PANEL 600MM (23.6")
MAXIMUM WIDTH 2400MM (94.4")
MOVEMENT TYPE MOTORISED
SHIPPING INFORMATION
SHIPPING DIMENSIONS Variable
SHIPPING WEIGHT Variable
DOWNLOADS / SUPPORT
TECHNICAL SHEET PDF DocumentMPM APPLICATION NOTES
